Commercial And Campsite Solar Cell Storage
Brand Dichu Equipment Technology (Shandong) Co., Ltd.
Product origin Weifang, China
Delivery time 15-20 days (can be expedited)
Supply capacity 5GW
Commercial and camp solar battery storage
Efficient energy storage: Using advanced energy storage technology, it can store solar energy quickly and efficiently, with a conversion rate far exceeding similar products, ensuring a stable power supply for commercial and camping areas.
Long-life design: Selected high-quality materials, after strict process processing, have excellent durability, greatly reduce replacement costs, and maintain stable performance after long-term use.
Flexible installation: The design is compact, lightweight and portable. Whether it is the roof or wall of a commercial place or various facilities in a camp, it can be easily installed to adapt to different terrains and space conditions.
Intelligent management system: Equipped with an intelligent monitoring and management system, it can monitor the battery status in real time, remotely control charging and discharging, and achieve reasonable allocation and efficient use of energy.
Safe and reliable: Multiple safety protection measures, including overcharge protection, over-discharge protection, short-circuit protection, etc., effectively prevent battery failures and safety hazards, and escort commercial operations and camping activities.
Strong adaptability: It can perfectly match various solar panels and is compatible with a variety of common electrical equipment to meet the diverse power needs of commercial and camping areas, whether it is lighting, office equipment or entertainment facilities.
Commercial and campsite solar battery storage
Product Overview
In today's era of pursuing sustainable development, commercial sites and camps have a growing demand for reliable and clean energy. Our solar battery storage system is designed to meet this demand. It can efficiently store the electricity generated by solar power generation equipment, provide stable power support for commercial operations and camp life, and help achieve energy self-sufficiency and green environmental protection.
| System Parameters | |||||||
Stable output power | 3680w | 4000w | 4600w | 5000w | 6000w | 3680w | 4000w |
| System rated range | 5.12-30.72kwh | ||||||
| Battery rating | LFP(LiFepo4) | ||||||
| Protection level | IP66（outdoor） | ||||||
| Battery module technical parameters | |||||||
| Battery module model | DC-Genius 5H-P | DC-Genius 10H-P | DC-Genius 15H-P | DC-Genius 20H-P | DC-Genius 25H-P | DC-Genius 30H-P | |
| Rated voltage | 51.2 V | ||||||
| Operating temperature range | ﹣20-+50℃ | ||||||
| Battery module size (width*height*thickness) mm | 650 x 620 x 180 | 650 x 980 x 180 | 650 x 1340 x 180 | 650 x 1700 x 180 | 650 x 1340 x 180 + 650 x 980 x 180 | 650 x 1340 x 180 + 650 x 1340 x 180 | |
| Certification | IEC62619, IEC63056, EN IEC61000-6-1, IEC61000-6-3, EN IEC62040-1, EN IEC62477-1, IEC60730-1 Annex H, IEC60529 IP66, UN38.3, MSDS, RoHS(2011/65/EU+2015/863),WEEE(2012/19/EU), ISTA | ||||||
| System Parameters | ||||
| Stable output power | 8000w | 10KW | 12KW | 15KW |
| 10KW-60KW | ||||
| Available capacity range | 9-54kw | |||
| LFP(LiFepo4) | ||||
| IP66（outdoor） | ||||
| Technical Parameters | ||||
| Inverter Model | DC-Genius 8000-T1 | DC-Genius 10K-T1 | DC-Genius12K-T1 | DC-Genius 15K-T1 |
| Phase | Three-phase | |||
| Maximum PV input voltage | 1000 V | |||
| Number of independent MPPTs | 2 | |||
| Rated grid frequency | 50 Hz/60 Hz | |||
| Communication | RS485/WIFI/4G(Optional) | |||
| show | LED+bluetooth+APP | |||
| Inverter size (width*height*thickness) mm | 420 x 520 x 226 mm | |||
| Battery module technical parameters | ||||
| Battery module model | DC-Genius 10HS——DC-Genius 60HS | |||
| Number of modules | 4-12 | |||
| Battery capacity | 10 kWh-60 kWh | |||
| Rated voltage | 204.8 V-614.4 V | |||
| Maximum operating current | 25 A | |||
| Operating temperature range | ﹣20-+50℃ | |||
| Certification | IEC62619, IEC63056, EN IEC61000-6-1, IEC61000-6-3, EN IEC62040-1, EN IEC62477-1 IEC60529 IP66, UN38.3, MSDS, RoHS(2011/65/EU+2015/863),WEEE(2012/19/EU), ISTA | |||
Key advantages
Efficient energy storage: Using advanced battery technology, it has high energy density and can store a large amount of electricity in a limited space. Whether it is daily electricity consumption in commercial places or the power demand of camps at night or on cloudy days, it can be easily handled.
Long life: High-quality battery materials and exquisite manufacturing processes ensure the long life and stability of the battery. After rigorous testing, the battery storage system can be charged and discharged thousands of times, greatly reducing the frequency and cost of battery replacement.
Intelligent management: Equipped with an intelligent battery management system (BMS), it can monitor the status of the battery in real time, including parameters such as voltage, current, and temperature, and perform intelligent adjustment and protection. Effectively prevent overcharging, over-discharging, short circuit and other problems, extend the battery life, and ensure the safe operation of the system.
Quick response: When the output power of solar power generation equipment changes or the demand of power equipment changes suddenly, it can respond quickly to ensure the stability and continuity of power supply. It avoids damage to equipment caused by power fluctuations and improves the reliability of power equipment.
Flexible configuration: The battery capacity and system scale can be flexibly configured according to different business and camping needs. Whether it is a small commercial store, a wild camp, or a large commercial park or resort, we can provide personalized solutions.
Environmental protection and energy saving: The use of renewable energy such as solar energy reduces dependence on traditional fossil energy and reduces carbon emissions. It not only meets environmental protection requirements, but also saves energy costs for users, achieving a win-win situation of economic and environmental benefits.
Application scenarios
Commercial places: Suitable for all kinds of commercial buildings, such as shopping malls, office buildings, hotels, factories, etc. It can be used as a backup power supply to ensure the normal operation of important equipment during power outages; it can also be combined with a solar power generation system to achieve self-sufficiency in commercial electricity and reduce operating costs.
Wild camps: Provide reliable power support for outdoor camping, exploration, scientific research and other activities. Meet various power needs such as lighting, communication, cooking, charging, etc., so that users can enjoy a comfortable and convenient life in the wild.
Off-grid communities: In some remote areas or off-grid communities, solar cell storage systems can be used as the main source of power supply. Solve the electricity problems of local residents and promote the development of the community and improve the quality of life.
Emergency rescue: In emergency situations such as natural disasters, it serves as an emergency power source to provide power support for rescue equipment and temporary settlements. Ensure the smooth progress of rescue work and provide basic living security for the affected people.
Installation and maintenance
Easy installation: The system adopts a modular design, and the installation process is simple and fast. There is no need for complex construction and professional technicians. Users can install it by themselves according to the instructions, or they can be installed and debugged by a professional team.
Easy maintenance: The intelligent battery management system can monitor the battery status in real time, and promptly detect and warn potential problems. Daily maintenance mainly includes regular inspection of the battery appearance, connection lines and ventilation conditions, etc., which is simple to operate and low cost.
